NSR-SDR-XS-HP-HDR
The NSR-SDR-X/S-HP-HDR is a high power/high speed configurable software defined radio supportingmultiple waveforms at X-Band transmit S-Band receive frequencies.
Key Characteristics
2025 – 2115 MHz (X-Band Optional 7145 – 7750 MHz)
Uplink Frequency
7900 – 8400 MHz
Downlink Frequency
10 Watts Linear RF
RF Power
Up to 1 Gbps
Downlink Data Rate
DVB-S2
Downlink Modulation
1 Kbps to 4 Mbps
Uplink Data Rate
BPSK (TC)
Downlink Modulation
LEO, MEO, GEO, and Cislunar/Lunar Applications
Orbits
Over the Air Reprogrammable
Options
AES-256 Encryption
Built in antenna switch for nadir and space-facing antennas
RF Antenna Switch
Direct to Earth
PCM/PSK/PM Tone and PN Ranging (Standard, Deep Space, Interstellar Modes)
DVB-S2
Waveform Selection
Flanged
Non-flanged
Mounting
28V
DC Power
Capability Readiness:
8
Technology Readiness Level (TRL)
9
Manufacturing Readiness Level (MRL)
Expected to fly 2026
Flight Heritage
